    Full Automatic PP Woven Bag Cutting And Sewing Machine PP HDPE European PC

    Descriptions :


    • Direct drive motor and two stretching unit in tape stretching line application, with automatic adjustment of die and the thickness online measuring system, a high efficiency and energy saving, hand provides high strength, low Daniel yarn production regulation.
    • Online thickness measurement system of application so that the film is more uniform, stable, saving the cost of raw materials, visualization of the automatic adjustment of die lip, has changed the traditional mould head adjusting mode, more intuitive, more convenient. (optional)
    • Cutting unit adopts six groups of non-stop change form, improve the production efficiency.
    • Auto winding machine use, more suitable for the demand of high speed tape stretching line.
    • Electrical control unit : adopt the European famous-brand processor control (PC) to monitor and control the whole line centrally and fully, bring the easier operation and more stability. (option)
    • Apply to produce the PP, HDPE normal tape, fibrillated tape, folded tape and some other flat-type tape with various specifications.

    Configuration
    StanderOption
    Material loading : Auto vacuum material feeding loaderAuto. adjust Die
    Film take off : With multi drives and moisture absorption unitMelt pump
    Automatic filterStatic mixer
    Water quench tank

    Screw type loader

    Mixing unit

    Gravimetric dosing

    Slitting UnitFlat tape folding unit
    Integrated holding unitFlat tape fibrillator unit
    Edge trim recycle and reefed systemFilm thickness gauge and control system
    Stretching section with 6 goddess, incl. heating unitIndustrial process computer / Europe
    Vacuum tape extraction incl. collection boxMulti stretching and annealing section
    Hot air oven, length 6 mAuto winding machine

    Technical Parameters
    Extruder
    Screw Diameter (mm)90105120135
    Max. Capacity (kg/h)4505508001000
    Screw Revolutions (r/min)20-150/20-200

    Technical Parameters
    Tape Stretching Line
    T-die Width (mm)800110015002x10002x1200
    Length Of Oven (m)6
    Max. Operating Speed (m/min)600
    Flat Thread Fibre Scope (tex)60-200
    No. Of Winders (Standard)132180216252264
