Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting

    Buy cheap Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting from wholesalers

    Buy cheap Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting from wholesalers
    • Buy cheap Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting from wholesalers

    Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting

    Ask Lasest Price
    Model Number : DFR-C
    Certification : CE、ISO
    Price : Depends on different model
    Payment Terms : L/C, T/T
    Supply Ability : 4 sets / 90 days
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting

    Descriptions Of DFR-C Series :


    DFR-C Series is used to produce vest bags subject to LDPE and HDPE cylindrical films. It features high production efficiency cause the programmable logic controller, high automation, servo, (stepping) motor length fixing, photovoltaic tracking, automatic punching, and automatic transport of finished products.


    According to your demands, we offer two kinds of model. The max width can reach 200-400 mmx 2, and length is 350-600 mmx 2, speed range keep in 120-160 pcs / min. In order to keep the machine safe, our normal package is wooden box but if the container is too tigher, we will package with PE film or pack with customer's requirment.


    Main Technical Parameters
    ModelDFR-C-400 x 2DFR-C-450 x 2
    Bag Making Width200-350 mm x 2200-400 mm x 2
    Bag Making Length350-600 mm x 2350-600 mm x 2
    Bag Making Thickness0.01-0.05 mm0.01-0.05 mm
    Speed Range120-160 pcs / min120-160 pcs / min
    Air Pressure5 kg / cm²5 kg / cm²
    Total Power7.57.5
    Weight16001800
    Dimension2500 * 12000 * 15002500 * 1300 * 1500

    Quality Professional Plastic Bag Manufacturing Machine Customizable DFR-C Heat Cutting for sale
