Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty

    Buy cheap Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty from wholesalers

    Buy cheap Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty from wholesalers
    • Buy cheap Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty from wholesalers
    • Buy cheap Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty from wholesalers

    Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty

    Ask Lasest Price
    Model Number : SCM
    Certification : CE
    Price : Depends on different model
    Payment Terms : L/C, T/T
    Supply Ability : 4 sets / 90 days
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Brushless DC Motor Plastic Mixing Machine / Color Dose Mixer 1 Year Warranty

    Color Dose Mixer Adopt Brush Less DC-Motor Owing to Easily Maintain


    Descriptions :


    With the function of permanent memory and storage. Use of brush less DC-motor, no need for maintenance. Use of micro-computer control, intelligentize to calculate accurately. Can satisfy the requirement of external signal input at the same time. The screw is handled with chrome to be durable. The modular structure is easy to assemble and disassemble, clean and exchange. Single color dose mixer's standard base equips hopper magnets to attract metal to protect the destroying of screw in injection machines. The stirrer is optional for single color does mixer, and should matched with stirrer controller to mix the material even. The double color dose mixer equips base with stirrer, can satisfy the request of mixing double materials. The main material hopper is standard equipment for double color dose mixer, optional for single color dose mixer.


    Main Technical Parameters
    ModelColor Dose Mix (Single)Color Dose Mix (Single)
    SCM30-12SCM30-14SCM30-16SCM30-12DMSCM30-14DMSCM30-16DM
    Output (kg/hr)0.3~80.5~161.1~30(0.3~8)x2(0.5~16)x2(1.1~30)x2
    Motor Power (W)50505050x250x250x2
    Motor Rotary Speed (rpm)0~30000~30000~30000~30000~30000~3000
    Materials Barrel10101010x210x210x2
    Reduction Ratio30:130:130:130:1/30:130:1/30:130:1/30:1
    Screw Diameter1214162-122-142-16
    Dimension (mm)H520520520600600600
    W590590590100010001000
    D355355355355355355
    Weight161616303030
