25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty

    Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers

    Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers
    • Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers
    • Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers
    • Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers
    • Buy cheap 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty from wholesalers

    25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty

    Ask Lasest Price
    Model Number : JC
    Certification : CE
    Price : Depends on different model
    Payment Terms : L/C, T/T
    Supply Ability : 4 sets / 90 days
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty

    Descriptions :


    Equipped with frequency conversion soft start-up device, and it will save 30% electricity, applied PLC and solid-state no spark heating control technology for temperature control, safe and stable. Adopt 12HP dual-system, dual-cold and high pressure cold planish machine in cooling system. Applied oil heating and cooling design to the screw to decrease scale, extend devices service time, save water and no longer use recycling water. With dual-vacuum online pinhole mounting hole endothermic and special design for board cutting control system, it integrated producing and edge trimming in one, convenient for operating, controlling and reducing the space.


    Main Technical Parameters
    ModelJC-75P2/200JC-135/180JC-150/200
    Screw dia. (mm)75/200135/180150/200
    Foaming rate (times)15-4515-4515-45
    Product width (mm)500-900400-900

    Flat-die : 500-1000

    Round-die : 2200

    Product thickness (mm)40-8035-4525-50
    Product density (kg/m3)20-8020-4020-50
    Output (kg/h)350-450300-350400-650
    Installed power (kw)280260280
    Actual power (kw)180180200
    Dimension (m)100x4x2.4100x4x2.4100x4x2.4

    Main Technical Parameters
    ModelJC-180/250JC-200/300JC-90P2/300
    Screw dia. (mm)180/250200/30090/300
    Foaming rate (times)15-4520-4515-45
    Product width (mm)

    Flat-die : 600-1100

    Round-die : 2200

    Flat-die : 600-1200

    Round-die : 2200

    500-1200
    Product thickness (mm)40-8050-10050-100
    Product density (kg/m3)20-8028-12028-120
    Output (kg/h)550-850650-900650-900
    Installed power (kw)350450450
    Actual power (kw)260300280
    Dimension (m)100x4x2.4100x4x2.4100x4x2.4

    Quality 25 - 160 Kg/H Output EPE Foam Machine 25 - 80 Mm Thickness Making 1 Year Warranty for sale
